LC213-KB-DP-S | Vandal Resistant SIP Video Intercom with 7" LCD & Keypad
Industrial SIP Video Intercom for Secure Communication Points | 7" LCD · HD Camera · Keypad · PoE/12V · IK10 · IP54 (NEMA 2 equivalent)· Stainless Steel | CE · FCC · RoHS · ISO 9001 | 2-Year Warranty
The LC213-KB-DP-S is a vandal resistant SIP video intercom with 7" LCD and keypad, designed for secure communication points where equipment must remain operational even in harsh environments and high-risk vandalism areas. The unit is built in a brushed stainless steel housing with an armored handset, HD infrared camera, large LCD display, and metal keypad, making it suitable for public access areas, industrial facilities, transport infrastructure, and secure buildings.
This intercom connects to a VoIP (SIP) network and allows two-way video communication between the field unit and a control room, security desk, reception, or monitoring center.
The device is designed for projects where reliability, durability, and clear communication are critical for safety and operations.
What Problems This Device Solves
This intercom is typically installed where customers need:
- Reliable communication in vandal-prone areas
- Video verification before granting access
- A fixed communication point that cannot be removed or damaged easily
- Direct connection to security desk / control room
- Hands-free or handset communication in noisy environments
- Keypad dialing to call different departments or numbers
- Integration into an existing SIP / VoIP system
- Continuous operation in outdoor or industrial environments
Where This Intercom Is Installed
Typical installation locations include:
- Parking garages and parking entrances
- Building entrances and access control points
- Prisons and correctional facilities
- Airports and railway stations
- Metro and bus stations
- Hospitals and emergency departments
- Industrial plants and warehouses
- ATMs and bank vestibules
- Universities and campuses
- Security checkpoints and gates
- Control points in large facilities
These are locations where standard plastic intercoms fail, but vandal-resistant equipment is required.
Communication & Call Routing
The intercom works over SIP / VoIP network.
When the call button is pressed:
- The device calls a predefined SIP number
- The call can go to:
- Security desk
- Reception
- Control room
- SIP phone
- Softphone on PC
- Video intercom master station
- Mobile phone (via SIP server)
- The operator sees video from the camera
- The operator can talk to the visitor
- The operator can open a door or gate via relay (if connected)
Display & Video Functions
The intercom is equipped with a 7" color LCD display used for:
- Video image of the person you are talking to
- Camera preview
- Video from control center
The unit includes a built-in HD infrared camera, allowing operation in low-light or night conditions.
Power & Network
The LC213-KB-DP-S supports flexible power options:
- PoE (Power over Ethernet IEEE 802.3af)
- PoE+
- 12V DC power supply
- Network connection via RJ45 (Cat5e or higher)
This allows installation using a single Ethernet cable when PoE is used.
Audio Quality (Important for Noisy Locations)
The unit is designed for industrial and public environments and includes:
- Noise-cancelling microphone
- Echo cancellation
- HD voice codecs
- Loud front speaker
- Handset with armored cord for noisy environments
This ensures clear communication even in factories, parking garages, and transport platforms.
Mounting & Installation
The intercom can be installed as:
- Wall-mounted
- Flush-mounted (recessed into the wall)
Installation features:
- Stainless steel mounting plate
- Security screws
- Rear cable entry (cables hidden inside the wall)
- Suitable for indoor and outdoor installation
- Designed for quick installation and easy maintenance
The hidden cable entry design prevents vandalism and cable cutting.
Key Technical Features
- SIP 2.0 (RFC3261)
- 7" TFT LCD display (1024×600)
- HD infrared camera
- H.264 video
- 16-digit metal keypad
- Armored handset
- Hearing aid compatible handset (HAC)
- Remote web configuration
- Remote firmware upgrade
- Relay control for door/gate
- Video streaming to server
- Android-based system
Typical System Architecture
The intercom works in a standard SIP system:
Intercom → PoE Switch → SIP Server → Security Desk / Control Room / PC / Phone
Video and audio are transmitted over the IP network, and the system can be centrally managed from the control center.
Summary – When to Choose LC213-KB-DP-S
This model is the right choice if you need:
- Vandal-resistant video intercom
- SIP / VoIP integration
- Video + audio communication
- Keypad dialing
- Large display
- Outdoor or industrial installation
- Flush or wall mounting
- PoE power
- Integration with security systems
- Reliable communication point that cannot be easily damaged
Order Information
LC213-KB-DP-S - Vandal Resistant Video Intercom with 7" LCD, Full metal Keypad, IP54, IK10, SIP / PoE
LC213-KB-DP-S Vandal Resistant SIP Video Intercom with 7" LCD & Keypad
General
- Vandal-resistant housing made of brushed stainless steel
- Protection rating: IP54
- Impact resistance: IK10
- Compliance: CE, FCC, RoHS, ISO9001
- Mounting: Wall mount / Flush mount
- Rear cable entry for hidden and tamper-resistant installation
- Corrosion-resistant hardware
- Designed for high reliability in harsh environments
- Operating system: Android 5.1
Video & Display
- Built-in HD infrared camera for low-light and night operation
- 7" HD LCD display
- Two-way real-time video communication
- Video can be transmitted to monitoring or recording server
- Video encoding: H.264, H.263
Audio
- Full duplex audio communication
- HD voice with noise reduction technology
- Echo cancellation supported
- ABS handset with noise-cancelling microphone
- Armored handset cord: 83 cm (32.7 in)
- Hearing aid compatible handset (HAC)
Keypad & Control
- 16-key zinc alloy vandal-resistant keypad
- Programmable speed dial buttons
- DTMF detection, generation, transmission and recovery
- Magnetic / electronic hook switch (no visible moving parts)
Network & Interface
- SIP VoIP communication, Standard SIP 2.0 (RFC3261) protocol
- WAN port supports DHCP to obtain IP automatically
- Configuration via web interface
- Connectors: RJ45, Cat5e or better
- Flexible hardware design with rich peripheral interfaces
- Remote management and firmware upgrade
Power Supply
- PoE (IEEE 802.3af / PoE+)
- External DC power option
- Low power consumption
- Heat dissipation design for continuous operation
Environmental
- Suitable for indoor and outdoor protected environments
- Resistant to humidity, dust, and mechanical impact
- Designed for industrial and public environments
Applications
- Parking lots and parking garages
- Prisons and correctional facilities
- Airports and transportation terminals
- Railway and metro stations
- Industrial plants and warehouses
- Hospitals and campuses
- Police stations and security checkpoints
- Stadiums and public areas
- Shopping malls and building entrances
- ATM and emergency assistance points
Dimensions & Weight
Unit Dimensions:
- 240 × 350 × 133 mm
- 9.45 × 13.78 × 5.24 inches
Shipping Dimensions:
- 500 × 320 × 170 mm
- 19.69 × 12.60 × 6.69 inches
Weight:
- Net weight: 5 kg (11.02 lb)
- Gross weight: 6 kg (13.23 lb)
Packaging
- Packaging materials: Pearl cotton (protective foam) + carton box
